Formlabs BioMed Elastic 50A Resin (Form 4) 1 L
Product# RS-C2-BMEL-01
BioMed Elastic 50A Resin is a soft, elastic, medical-grade material for applications requiring comfort, biocompatibility, and transparency. This ISO 10993 and USP Class VI certified material is made in an FDA-registered, ISO 13485 facility and can be used in applications for long-term skin contact (>30 days), and short-term mucosal membrane contact (<24 hours).
Please note: only compatible with Form 4B
Dont't Forget an Extended Warranty!
利用可能
医療関係者向け
価格情報や詳細につきましては、「医療関係者の方」がお問い合わせくださいますようお願いいたします。
弊社略歴
Bruleは、他社に先駆けて2012年から３Dプリンター販売を開始いたしました。その後も、市場評価の高い卓上型プリンタを厳選して、販売からサポートまで社内で手掛けているのが特徴です。経験豊かな技術者が社内に数多く在籍しております。
弊社概要
Bruleは、3Dプリンターのサプライヤーであり、産業用および、卓上型の3Dプリントそれぞれに精通しています。弊社は、最先端の次世代金属3Dプリンター、SLS、超高速産業用3Dプリンターも取り扱っております。
顧客満足
- 厳選されたセレクション
- 迅速な配送
商品概要
Formlabs BioMed Elastic 50A Resin (Form 4) 1 L
BioMed Elastic 50A Resin (Form 4) 1 L is a soft, elastic, medical-grade material for applications requiring comfort, biocompatibility, and transparency. This ISO 10993 and USP Class VI certified material is made in an FDA-registered, ISO 13485 facility and can be used in applications for long-term skin contact (>30 days), and short-term mucosal membrane contact (<24 hours).
Compatibility
Printer compatibility: Form 3B, Form 3B+, Form 3BL
Compatible with these resin tanks: Form 3/3B Resin Tank V2, Form 3/3B Resin Tank V2.1, Form 3L/3BL Resin Tank V1, Form 3L/3BL Resin Tank V2, Form 3L/3BL Resin Tank V3
Compatible with these build platforms: Form 3 Build Platform, Form 3 Build Platform 2, Form 3 Stainless Steel Build Platform, Form 3L Build Platform, Form 3L Build Platform 2L
Why Choose Formlabs BioMed Elastic 50A Resin (Form 4) 1 L?
Fuel medical innovation using 3D printing and BioMed Elastic 50A Resin (Form 4) 1 L, from comfortable, patient-specific medical devices to soft tissue medical models surgeons can reference in the operating room (O.R.)
Comfortable
Produce mass-personalized, medical-grade parts that are comfortable and feel great.
Soft
Produce soft tissue models that feel similar to human tissue and deliver biomechanical behaviors that are ideal for creating full-size hearts, gastrointestinal models, or small complex neurovascular models to bring into the O.R.
Transparent
Parts produced using this material appear transparent and clear to view how tools or objects flow within parts.
Medical-Grade Material, Biocompatible Parts
Leverage a material manufactured within our Quality Management Systems, with strict adherence to ISO 13485. Instill confidence that this material is suitable for biocompatible applications with long-term skin (>30 days), short-term mucosal membrane contact (<24 hours), and USP Class VI certifications.
Applications*
Directly 3D print soft, elastic parts requiring biocompatibility with BioMed Elastic 50A Resin (Form 4) 1 L. Reduce workflow times by eliminating molding to directly produce comfortable, patient-specific medical devices or soft tissue medical models surgeons can reference in the O.R.
BioMed Elastic 50A Resin (Form 4) 1 L is ideal for:
Comfortable medical devices requiring long-term skin contact- Soft tissue models, including organs, muscle, skin, and small vasculature
*Unlike Formlabs Dental Resins, no intended uses are provided for BioMed Resins. Material properties may vary based on part design, manufacturing practices, and other methods. It is the manufacturer’s responsibility and its respective customers and end-users to determine the biocompatibility and performance of all printed parts for their respective application and use. To instill confidence in potential users, Formlabs has tested biocompatibility and sterilization compatibility for common use cases and manufactures BioMed Resins in an ISO 13485-certified facility. We can offer representative examples of what customers have done with our products and the supporting documentation we make freely available.
Formlabs manufactures our Biomed and Medical Device Resins at our FDA Registered facility in Ohio. These materials are designed and manufactured within our robust Quality Management System that is ISO 13485 and EU MDR certified. A dedicated team of operators and quality assurance professionals make the resins inside a certified ISO Class 8 clean room. All of our Medical Device Resins are appropriately registered with FDA and CE marked according to the EU MDR.
Material Properties*
- Ultimate Tensile Strength 2.3 MPa
- Stress at 50% Elongation 1 MPa
- Stress at 100% Elongation 1.3 Mpa
- Elongation 150%
- Tear Strength 11 kN/m
- Hardness Shore A 50A
*Material properties may vary based on part geometry, print orientation, print settings, temperature, and disinfection or sterilization methods used. Data were measured on post-cured samples printed on a Form 3B/+ with 100µm BioMed Elastic 50A Resin (Form 4) 1 L settings, washed in a Form Wash for 20 minutes in 99% Isopropyl Alcohol, and cured at 70°C, 30 minutes submerged in water in a Form Cure according to the Manufacturing Guide. BioMed Elastic 50A Resin (Form 4) 1 L was tested at NAMSA World Headquarters, OH, USA.
